Description
This machine is a portable and high quality 3-channel ECG, which offer not only normal thermal printing but also external printing
solution. It can used in hosipital. Clinic and emergencyies.
Features:
1. 3 channel ECG machine with automatic interpretation
2. Manual/Auto working Modes
3. Simultaneous 12 leads acquisition and 3-ch recording with high resolution thermal printer.
4. 4.3 inch Color TFT LCD display ECG wave and friendly menu setting.
5. Support touch panel and keypad input ways
Support SD card storage.
6. 120 seconds ECG wave freeze and replay function.
7. Lead-off detection and alert
8. Digital filtering, resisting baseline drift, AC and EMG interference
9. Built in USB/RS232 interface(ECGNET software optional)
10. Built in rechargeable Li-ion battery support less than 3 hours continuously work.
11. AC power supply at 90-240V@50/60Hz
Technical Specification:
Lead: standard 12 leads
Lead acquisition: 16bit/24bit 1000Hz(synchronously 12 leads)
Work modes: MANUAL,AUTO modes
Filter:
AC Flter : 50Hz / 60Hz
EMG Filter : 35Hz / 45Hz
Anti-Drift Filter : 0.15Hz (Adaptive)
CMMR: ≥100dB (with AC filter)
Input circuit: floating; protection circuit against defibrillator effect
Input Impedance: ≥50MΩ
Input circuit current: ≤0.05μA
Input dynamic range: ±5mVpp
Patient current leakage: <10μA
Calibrating voltage: 1mV±2%
Voltage tolerance:±600mV
Time constant: ≥3.2s
Frequency response: 0.05~150Hz(-3db)
Noise level: <15μVp-p
Sensitivity valve: ≤20μV
Sensitivity: 2.5, 5,10,20mm/mV
Inter-channel Interference: ≤0.5mm
Paper speed:5, 10, 12.5, 25, 50mm/s(±3%)
100 patient information storage.
Display:
4.3 inch TFT LCD with touch panel.
